Self-locking eye hook, Exoset G100, SpanSet
Key features
- Chain diameter6 mm, 8 mm, 10 mm, 13 mm, 16 mm
- WLL1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg
- WLL (tonnes)1,4 t, 2,5 t, 4 t, 6,7 t, 10 t
- Dimensions108 mm, 135 mm, 165 mm, 205 mm, 255 mm
- Dimension B70 mm, 90 mm, 108 mm, 138,5 mm, 170,5 mm
- Length dimension141 mm, 175 mm, 212,5 mm, 270 mm, 331 mm
What it is
Self-locking eye hook, Exoset G100, SpanSet. Key specifications: chain diameter 6 mm, 8 mm, 10 mm, 13 mm, 16 mm, WLL 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg, WLL (tonnes) 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t.
Chain fittings are hooks, shackles, master links and snap hooks that connect chains, ropes and straps to the load or to the attachment point.
What it is for
Used for anchoring to walls, ceilings and floors.
How to use it
Match each fitting to the size and grade of the chain or rope, and check that its rated capacity is at least equal to that of the rest of the sling assembly. For lifting, use only marked and certified parts: brass snap hooks and hardware-store hooks are for light duty, not suspended loads. Always close safety latches and shackle pins, and discard deformed or worn parts.
Where it is used
- Industrial construction
- Residential construction
- Logistics and warehousing
Technical data
- Chain diameter: 6 mm, 8 mm, 10 mm, 13 mm, 16 mm
- WLL: 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg
- WLL (tonnes): 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t
- Dimensions: 108 mm, 135 mm, 165 mm, 205 mm, 255 mm
- Dimension B: 70 mm, 90 mm, 108 mm, 138,5 mm, 170,5 mm
- Length dimension: 141 mm, 175 mm, 212,5 mm, 270 mm, 331 mm
- Height dimension: 20 mm, 26 mm, 30 mm, 40,5 mm, 50,5 mm
- Dimension I: 21 mm, 27 mm, 34,5 mm, 40 mm, 50 mm
- Dimension K: 43 mm, 51 mm, 64,3 mm, 80 mm, 104 mm
- Dimension O: 28 mm, 35,5 mm, 45 mm, 53,5 mm, 62 mm
- Weight: 0,5 kg, 0,9 kg, 1,5 kg, 2,7 kg, 5,7 kg
- Regulations: EN 1677
Who it is for
Designed for formwork carpenters, crane operators and building maintenance operatives.
Related products
- Self-locking swivel hook, Exoset G100, SpanSet
- Shortening hook with safety pin, Exoset G100, SpanSet
- Ratchet tensioner with eyelets EXOSET® G100 SpanSet — from the category Lifting and Towing Chains
- Hinged corner protector Secutex SpanSet — from the category Lifting Slings
- Brass-plated clear washing line wire, 100m, 4mm, Vigor — from the category Galvanised or Stainless Steel Cables and Wire Rope Kits
- Browse the whole category: Chains and Accessories
Before you order
In your request, please state the length, the diameter and the quantities required, so we can give you the right quotation first time.
For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
Quantity
Specifications 13
| Item code | G100 |
|---|---|
| Chain diameter | 6 mm, 8 mm, 10 mm, 13 mm, 16 mm |
| WLL | 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg |
| WLL (tonnes) | 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t |
| Dimensions | 108 mm, 135 mm, 165 mm, 205 mm, 255 mm |
| Dimension B | 70 mm, 90 mm, 108 mm, 138,5 mm, 170,5 mm |
| Length dimension | 141 mm, 175 mm, 212,5 mm, 270 mm, 331 mm |
| Height dimension | 20 mm, 26 mm, 30 mm, 40,5 mm, 50,5 mm |
| Dimension I | 21 mm, 27 mm, 34,5 mm, 40 mm, 50 mm |
| Dimension K | 43 mm, 51 mm, 64,3 mm, 80 mm, 104 mm |
| Dimension O | 28 mm, 35,5 mm, 45 mm, 53,5 mm, 62 mm |
| Weight | 0,5 kg, 0,9 kg, 1,5 kg, 2,7 kg, 5,7 kg |
| Regulations | EN 1677 |
Compare with similar models
Technical data declared by the manufacturers. An empty cell means the figure is not declared.
| Feature |
This model
Self-locking eye hook, Exoset G100, SpanSet
|
Self-locking fork hooks, Exoset G100, SpanSet
|
Eye hooks with safety latch, Exoset G100, SpanSet
|
Self-locking swivel hook, Exoset G100, SpanSet
|
|---|---|---|---|---|
| Brand | SpanSet | SpanSet | SpanSet | SpanSet |
| Chain diameter | 6 mm, 8 mm, 10 mm, 13 mm, 16 mm | 6 mm, 8 mm, 10 mm, 13 mm, 16 mm | 6 mm, 8 mm, 10 mm, 13 mm, 16 mm | 8 mm, 10 mm, 13 mm, 16 mm |
| WLL | 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg | 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg | 1400 kg, 2500 kg, 4000 kg, 6700 kg, 10000 kg | 2500 kg, 4000 kg, 6700 kg, 10000 kg |
| WLL | 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t | 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t | 1,4 t, 2,5 t, 4 t, 6,7 t, 10 t | 2,5 t, 4 t, 6,7 t, 10 t |
| Dimensions | 108 mm, 135 mm, 165 mm, 205 mm, 255 mm | 94 mm, 118 mm, 140 mm, 177 mm, 220 mm | 79 mm, 98 mm, 121 mm, 153 mm, 185 mm | 196 mm, 224 mm, 269 mm, 335 mm |
| Dimension B | 70 mm, 90 mm, 108 mm, 138,5 mm, 170,5 mm | 70 mm, 90 mm, 109 mm, 138,5 mm, 170,5 mm | 68,5 mm, 105,5 mm, 134 mm, 160,5 mm | 90 mm, 108 mm, 138,5 mm, 170,5 mm |
| Length dimension | 141 mm, 175 mm, 212,5 mm, 270 mm, 331 mm | 131 mm, 166 mm, 196,5 mm, 251 mm, 303 mm | 111 mm, 137,5 mm, 171,5 mm, 219 mm, 260 mm | 229 mm, 269 mm, 330 mm, 413 mm |
| Height dimension | 20 mm, 26 mm, 30 mm, 40,5 mm, 50,5 mm | 20 mm, 26 mm, 30 mm, 40,5 mm, 50,5 mm | 21 mm, 27,5 mm, 33 mm, 43,5 mm, 50 mm | 20 mm, 26 mm, 33 mm, 50,5 mm |
| Dimension I | 21 mm, 27 mm, 34,5 mm, 40 mm, 50 mm | 7,5 mm, 9,5 mm, 12 mm, 15 mm, 17,5 mm | 10 mm, 11 mm, 16 mm, 19 mm, 24,5 mm | 13 mm, 16 mm, 17 mm, 22 mm |
