Locking pulley Spin L2 Petzl

What it is

SPIN L2 (code P001CA00) is a Petzl pulley, compliant with EN 12278. It is intended for professional use in work at height, rope access and rescue, in accordance with the manufacturer's instructions.

The rope pulley is a compact sheave with bearings, in an openable metal frame, used in work at height and in rescue to change the direction of the rope or to reduce the effort required; some models have an integrated rope clamp.

What it is for

Used for work at height, where access and restraint must be ensured for the whole job and for lifting loads, with accessories rated for the weight involved.

How to use it

Choose according to the rope diameter and the stated working load. Open the side plate, insert the rope into the groove and close it again, then connect it to the anchor point with a suitable karabiner, checking that the rope runs freely and in the correct direction. Use requires specific training: before each use, inspect it and withdraw it if it has cracks, wear or a damaged groove.

Where it is used

• Urban green space maintenance
• Civil protection
• Fire and rescue services

Technical data

• Regulations: EN 12278
• Weight (g): 480
• Rope diameter (min max) (mm): 7 - 13
• Pulley type: Watertight ball bearings
• Pulley diameter (mm): 38
• Maximum working load: 8 kN (3 kN per leg)
• Breaking load (kN): 36
• Efficiency: 95%
• Material: Aluminium, stainless steel, polyamide
• Warranty: 3 years

Who it is for

Designed for building maintenance operatives, forestry workers, arborists and health and safety officers.
