Type A – C External Corner Anchor, CSC Edilizia 411M
Key features
- Length (mm)280
- Holes (mm)Ø 18
- Slots32x55 mm
- Weight (kg)10
What it is
The CSC Edilizia 411M external corner anchor is a lifeline device for type A and type C uses, designed to handle the external corners of the line route. With a length of 280 mm and a weight of 10 kg, it is fitted with Ø18 mm holes and 32x55 mm slots for structural fixing, offering flexibility in positioning on anchor points.
Lifeline anchors are certified posts, brackets and fixed points that are secured to the roof or structure for attaching lifelines and fall arrest devices.
What it is for
Used as an anchor point in fall protection systems, for roof maintenance and for fall protection, as part of a fall arrest or work restraint system.
How to use it
They are installed to design by a qualified installer, on a verified substrate (timber, concrete, steel, metal sheeting), using the fixings specified by the manufacturer. On completion, the installer issues the declaration and documentation, and the required periodic inspections are carried out. Workers check the anchor before clipping on and do not use it if it is deformed or has already arrested a fall.
Where it is used
- Industrial construction
- Residential construction
- Workplace safety and PPE
Technical data
- Length (mm): 280
- Holes (mm): Ø 18
- Slots: 32x55 mm
- Weight (kg): 10
Who it is for
Designed for formwork carpenters, building maintenance operatives and health and safety officers.
Related products
- Type C External Corner Anchor, CSC Edilizia 601H
- Type A – C External Corner Anchor, CSC Edilizia
- Widened base, double-tilt, for combo poles, CSC Edilizia — from the category Lifeline Accessories
- Trauma Strap anti-trauma safety device Neri 121172 — from the category Fall Arrest Harnesses
- Rope with eyelets (for operator ascent), galvanised and stainless steel, CSC Edilizia — from the category Ropes and Temporary Lifelines
- Browse the whole category: Horizontal and Vertical Lifeline Anchors
Before you order
In your request, please state the length and the quantities required, so we can give you the right quotation first time.
For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
Quantity
Specifications 5
| Item code | 411M |
|---|---|
| Length (mm) | 280 |
| Holes (mm) | Ø 18 |
| Slots | 32x55 mm |
| Weight (kg) | 10 |
