Circular saw 65mm 1350W DeWalt DWE560-QS

What it is

The DeWalt DWE560-QS circular saw is a versatile corded machine for cutting timber with greater depth capacity. Equipped with a 184 mm diameter blade and a 16 mm bore, it reaches 5,500 rpm no-load with an output power of 850 W. It makes cuts of up to 65 mm at 90° and 42 mm at 45°, ideal for beams and thick panels. With a weight of 3.7 kg, a length of 286 mm and a height of 226 mm, it remains easy to handle while offering superior performance.

A circular saw is a corded or cordless power tool with a rotating blade for straight cuts in wood and panels; this category includes plunge saws, band saws and table saws.

What it is for

Used for woodworking in the joinery shop and for cutting solid wood, panels and battens, on the bench or on site.

How to use it

Fit the blade suited to the material, observing the direction of rotation, set the depth just beyond the material thickness and clamp the workpiece. Start the blade before it touches the workpiece and feed steadily along the line or guide rail, without forcing or lifting the machine during the cut. Check that the lower guard always returns to its position, wear safety glasses and ear defenders, and connect dust extraction whenever possible.

Where it is used

• Residential construction
• Renovation

Technical data

• Blade bore (mm): 16
• No load speed (rpm): 5500
• Weight (kg): 3,7
• Height (mm): 226
• Max cutting depth at 45° (mm): 42
• Power output (W): 850
• Max cutting depth at 90° (mm): 65
• Vibration uncertainty K1: 1,5
• Blade diameter (mm): 184
• Power supply: Wire type
• Length (mm): 286
• Power (W): 1350

Who it is for

Designed for formwork carpenters and joiners.
