Lifting platform IM 220 Imer Group

What it is

Lifting platform IM 220 Imer Group. Key specifications: type Diesel-electric scissor lift for indoor/outdoor use, model IM 14220, IM 17220, maximum working height (mm) 16200 / 19000.

A mobile elevating work platform is a scissor, boom or spider machine with a basket or work deck that lifts people and tools to height.

What it is for

Used for work at height, where access and restraint must be ensured for the whole job and for lifting people, with equipment designed for access at height.

How to use it

It must be operated only by trained and certified personnel. Before use, check that the ground is firm and level, test the controls and the emergency lowering and, on spider models, deploy and level the outriggers. In the basket, stay clipped on with your harness at the designated anchor point, do not exceed the rated load and manoeuvre slowly, away from power lines and with wind speed within the rated limit.

Where it is used

• Commercial construction
• Industrial construction
• Industrial plant engineering

Technical data

• Type: Diesel-electric scissor lift for indoor/outdoor use
• Model: IM 14220, IM 17220
• Maximum working height (mm): 16200 / 19000
• Capacity (kg): 800 / 540
• Platform extension (m): 2 front + 0.9 rear
• Motor: diesel 23 kW / electric AC 48V 15 kW
• Traction battery (V/Ah): 48 / 630
• Transmission: hydrostatic 4WD
• Wheel dimensions (mm): 815 x 295
• Oil tank capacity (L): 100
• Weight (kg): da 7950 a 8600

Who it is for

Designed for electricians, building maintenance operatives and industrial maintenance technicians.
