A.M.E.S. srlHose with galvanised steel spiral
Carry water for irrigating, washing and supplying machines in the garden and on site.
All Wortex products
Electric pumps CH-BR Wortex
Key features
- Liquid temperatureUp to 35°C (household use); max 90°C (other uses)
- Ambient temperatureUp to 40°C
- Gauge suction height (m)up to 7
- MotorInduction, 2-pole (2850 rpm), Class F, IP 55
- Pump bodyCast iron
- ImpellerBrass
What it is
Electric pumps CH-BR Wortex. Key specifications: liquid temperature Up to 35°C (household use); max 90°C (other uses), ambient temperature Up to 40°C, gauge suction height (m) up to 7.
A clean water pump is a surface or submersible electric pump that lifts or pressurises clear water from wells, cisterns and tanks.
What it is for
Used in irrigation systems, from the water supply point to the emitter and for pumping water out of excavations, tanks and sumps.
How to use it
Install surface pumps on a level base close to the draw-off point, with a foot valve on the suction pipe, and fill them with water before first start-up; lower submersible pumps suspended on a rope. Use them only with clean, sand-free water and never let them run dry. Connect them to a circuit protected by an RCD and, in winter, drain outdoor pumps to protect them from frost.
Where it is used
- Building services
- Water engineering works
Technical data
- Liquid temperature: Up to 35°C (household use); max 90°C (other uses)
- Ambient temperature: Up to 40°C
- Gauge suction height (m): up to 7
- Motor: Induction, 2-pole (2850 rpm), Class F, IP 55
- Pump body: Cast iron
- Impeller: Brass
- Shaft: Stainless steel AISI 304
- Mechanical seals: Ceramic/graphite/NBR
Who it is for
Designed for plumbers.
Related products
- Electric pumps CN 32 Wortex
- Electric pumps CB 40 Wortex
- Water hose WAY — from the category Water Hoses and Layflat Hoses
- Straight double-union brass connector — from the category Galvanised Pipe Fittings
- Modular underground tanks, Nanotank "Canotto" shape, polyethylene, Rototec — from the category Tanks, Cisterns and Drums for Liquid Storage
- Browse the whole category: Clean Water Pumps
Before you order
Tell us the quantities you need and the intended use: if there is a more suitable version, or an equivalent available sooner, we will let you know.
For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
Quantity
Specifications 8
| Liquid temperature | Up to 35°C (household use); max 90°C (other uses) |
|---|---|
| Ambient temperature | Up to 40°C |
| Gauge suction height (m) | up to 7 |
| Motor | Induction, 2-pole (2850 rpm), Class F, IP 55 |
| Pump body | Cast iron |
| Impeller | Brass |
| Shaft | Stainless steel AISI 304 |
| Mechanical seals | Ceramic/graphite/NBR |
