Electric pumps VM 16 Wortex

What it is

Electric pumps VM 16 Wortex. Key specifications: domestic use liquid temperature, EN 60335 2 41 Up to 35°C, maximum liquid temperature, other uses 110°C, ambient temperature Up to 40°C.

A clean water pump is a surface or submersible electric pump that lifts or pressurises clear water from wells, cisterns and tanks.

What it is for

Used in irrigation systems, from the water supply point to the emitter and for pumping water out of excavations, tanks and sumps.

How to use it

Install surface pumps on a level base close to the draw-off point, with a foot valve on the suction pipe, and fill them with water before first start-up; lower submersible pumps suspended on a rope. Use them only with clean, sand-free water and never let them run dry. Connect them to a circuit protected by an RCD and, in winter, drain outdoor pumps to protect them from frost.

Where it is used

• Building services
• Water engineering works

Technical data

• Domestic use liquid temperature, EN 60335 2 41: Up to 35°C
• Maximum liquid temperature, other uses: 110°C
• Ambient temperature: Up to 40°C
• Motor: Electric induction 2-pole (2900 rpm)
• Insulation: Class F
• Protection: IP55
• Mechanical seals: Silicon/silicon/Viton

Who it is for

Designed for plumbers.

Related products

• Electric pumps VM 20 Wortex
• Electric pumps PM BR Wortex
• PrimoFlex Premium flexible hose 5/8" – 25m Kärcher — from the category Water Hoses and Layflat Hoses
• Reducers M/F art. 241 — from the category Galvanised Pipe Fittings
• Storage container for palletised drums Sall — from the category Tanks, Cisterns and Drums for Liquid Storage
• Browse the whole category: Clean Water Pumps

Before you order

Tell us the quantities you need and the intended use: if there is a more suitable version, or an equivalent available sooner, we will let you know.

For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
