Raimondi e-FOX professional battery-powered tile beater and float

Applications

The Raimondi e-FOX professional cordless tile vibrator and float is intended for professional use in the following contexts:

• Construction sites, infrastructure, and plants
• Workshops, laboratories, and industrial production
• Specialized technical maintenance
• Operators and professionals in the Large Format sector

Standards and Compliance

Reference regulations: CE marking according to EU directives applicable to the Large Format sector, compliance with current technical and safety regulations, technical documentation provided by the manufacturer Raimondi.

e-FOX professional cordless tile vibrator and rubber float (Raimondi — Large Formats) — Professional cordless tile vibrator designed to vibrate large format tiles to expel air from under the slab and ensure complete slab-adhesive contact;

Technical Specifications

Features

• Professional cordless tile vibrator designed to vibrate large format tiles to expel air from under the slab and ensure complete slab-adhesive contact;
• Extremely effective also for perfect bonding of waterproofing and/or decoupling membranes;
• Battery powered: no more cables hindering work;
• Battery with long autonomy (it is possible to vibrate between 150 and 200 m2 with a single charge) and long life (500 charging cycles – equivalent to approximately 100,000 m2 vibrated – before performance begins to decline);
• Model 321BATPRR: vibrating area 21×41 cm ideal for vibrating large format slabs with maximum speed and effectiveness, steps and columns. Vibrating area reducible to 15×15 cm by removing the outer plate;
• Model 321BATRVR: vibrating area 15×15 cm ideal for wall use and for vibrating small format tiles. Vibrating area extendable to 21×41 cm by adding the optional plate;
• Ideal for both floor and wall use thanks to its extremely low weight (5.8 kg with 24×41 cm vibrating plate; 3.1 kg with 15×15 cm vibrating plate);
• Vibrating area (plate) in rigid PVC to maximize vibration effectiveness and minimize friction on the slab/tile and/or membrane;
• The constant, controlled, and uniformly applied vibration does not damage the slab even in the most critical situations (such as when large holes or cuts have been made on the slab);
• Equipped with 3 handles: two side handles for two-hand use, one central handle for single-hand use;
• High vibration frequency (motor rpm: 3,500);
• Motor: 15V DC, battery power 38.5 Wh;
• Supplied with padded protective bag (with both handles and shoulder strap) ideal for transport and storage.

Why choose Raimondi

• Processing Specialist: Modena-based company, leader in professional tools for tiles, marble, and stone
• Complete Range: LAB machines, large format equipment, suction cups, R.L.S. leveling systems, spacers, tile cutters, and diamond blades
• Precision and Efficiency: tools designed for high-quality results in surface processing
• Made in Italy: experience and innovation at the service of installation professionals

Request a quote from AMES Srl for the e-FOX professional cordless tile vibrator and rubber float: we will contact you with models, accessories, and supply conditions.
