Electric pumps CNB-BR Wortex
Also known as: electric water pump
Key features
- Domestic use liquid temperature, EN 60335 2 41Up to 35°C
- Maximum liquid temperature, other uses35°C
- Ambient temperatureUp to 40°C
- Gauge suction height (m)up to 7
- ServiceContinuous
- MotorElectric induction 2-pole (2850 rpm)
What it is
Electric pumps CNB-BR Wortex. Key specifications: domestic use liquid temperature, EN 60335 2 41 Up to 35°C, maximum liquid temperature, other uses 35°C, ambient temperature Up to 40°C.
A clean water pump is a surface or submersible electric pump that lifts or pressurises clear water from wells, cisterns and tanks.
What it is for
Used in irrigation systems, from the water supply point to the emitter and for pumping water out of excavations, tanks and sumps.
How to use it
Install surface pumps on a level base close to the draw-off point, with a foot valve on the suction pipe, and fill them with water before first start-up; lower submersible pumps suspended on a rope. Use them only with clean, sand-free water and never let them run dry. Connect them to a circuit protected by an RCD and, in winter, drain outdoor pumps to protect them from frost.
Where it is used
- Building services
- Water engineering works
Technical data
- Domestic use liquid temperature, EN 60335 2 41: Up to 35°C
- Maximum liquid temperature, other uses: 35°C
- Ambient temperature: Up to 40°C
- Gauge suction height (m): up to 7
- Service: Continuous
- Motor: Electric induction 2-pole (2850 rpm)
- Insulation: Class F
- Protection: IP55
- Pump body: Cast iron
- Motor support: Cast iron
- Impeller: Brass
- Diffuser: Noryl
- Drive shaft: Stainless steel
- Mechanical seals: Ceramic/graphite/NBR
Who it is for
Designed for plumbers.
Related products
- Electric pumps PM BR Wortex
- Electric pumps CN 80 Wortex
- Braided clear PVC tubing — from the category Water Hoses and Layflat Hoses
- Union fitting MF flat seat art. 331 - 1'1/2 — from the category Galvanised Pipe Fittings
- Tank with electric pump for diesel transfer DCC 200 Wortex — from the category Tanks, Cisterns and Drums for Liquid Storage
- Browse the whole category: Clean Water Pumps
Before you order
Tell us the quantities you need and the intended use: if there is a more suitable version, or an equivalent available sooner, we will let you know.
For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
Quantity
Specifications 14
| Domestic use liquid temperature, EN 60335-2-41 | Up to 35°C |
|---|---|
| Maximum liquid temperature, other uses | 35°C |
| Ambient temperature | Up to 40°C |
| Gauge suction height (m) | up to 7 |
| Service | Continuous |
| Motor | Electric induction 2-pole (2850 rpm) |
| Insulation | Class F |
| Protection | IP55 |
| Pump body | Cast iron |
| Motor support | Cast iron |
| Impeller | Brass |
| Diffuser | Noryl |
| Drive shaft | Stainless steel |
| Mechanical seals | Ceramic/graphite/NBR |
