Plunge saw 1300W with 1.5m straight guide rail, TSTAK, DeWalt

What it is

The DeWalt DWS520KTR-QS plunge saw is a corded power tool with a rated input power of 1300 W, fitted with a 165 mm diameter blade and a 20 mm bore. The no-load speed, adjustable from 1750 to 4000 rpm, makes it possible to adapt the cut to the material, while cutting depths reach 59 mm at 90° and 44 mm at 45°. Supplied with a 1.5 m straight guide rail and a TSTAK case, it promotes accurate straight cuts and tidy transport. The body weighs 5 kg and is compact in size (265 mm in height and 303 mm in length).

A circular saw is a corded or cordless power tool with a rotating blade for straight cuts in wood and panels; this category includes plunge saws, band saws and table saws.

What it is for

Used for woodworking in the joinery shop and for cutting solid wood, panels and battens, on the bench or on site.

How to use it

Fit the blade suited to the material, observing the direction of rotation, set the depth just beyond the material thickness and clamp the workpiece. Start the blade before it touches the workpiece and feed steadily along the line or guide rail, without forcing or lifting the machine during the cut. Check that the lower guard always returns to its position, wear safety glasses and ear defenders, and connect dust extraction whenever possible.

Where it is used

• Residential construction
• Renovation

Technical data

• Blade bore (mm): 20
• No load speed (rpm): 1750 - 4000
• Height (mm): 265
• Weight (kg): 5
• Blade diameter (mm): 165
• Max cutting depth at 45° (mm): 44
• Max cutting depth at 90° (mm): 59
• Power supply: Wire type
• Absorbed power (W): 1300
• Length (mm): 303

Who it is for

Designed for formwork carpenters and joiners.
