CSC EdiliziaType C Variable Internal Angle Anchors, CSC Edilizia 601PCode 601P
Build and complete horizontal and vertical fall arrest lifelines with certified components.
Accessories collection:Lifeline AccessoriesGalvanised or Stainless Steel Cables and Wire Rope KitsFall Arrest Harnesses
All CSC Edilizia products
Internal Corner Anchor, CSC Edilizia 609-609C
Key features
- MaterialS235JR (Fe 360 B)
- TreatmentGalvanised
- RegulationsUNI-ISO 2768
- Weight (kg)3,96
- Dimensions (cm)36 × 36 × 6
What it is
The CSC Edilizia 609-609C internal corner anchor is a component for fall arrest systems and lifelines, made of S235JR (Fe 360 B) steel with a galvanising treatment for corrosion protection. Weighing 3.96 kg and measuring 36 × 36 × 6 cm, it is designed to be installed at internal corners, following the general tolerances of the UNI-ISO 2768 standard.
Lifeline anchors are certified posts, brackets and fixed points that are secured to the roof or structure for attaching lifelines and fall arrest devices.
What it is for
Used as an anchor point in fall protection systems, for roof maintenance and for fall protection, as part of a fall arrest or work restraint system.
How to use it
They are installed to design by a qualified installer, on a verified substrate (timber, concrete, steel, metal sheeting), using the fixings specified by the manufacturer. On completion, the installer issues the declaration and documentation, and the required periodic inspections are carried out. Workers check the anchor before clipping on and do not use it if it is deformed or has already arrested a fall.
Where it is used
- Industrial construction
- Residential construction
- Workplace safety and PPE
Technical data
- Material: S235JR (Fe 360 B)
- Treatment: Galvanised
- Regulations: UNI-ISO 2768
- Weight (kg): 3,96
- Dimensions (cm): 36 × 36 × 6
Who it is for
Designed for formwork carpenters, building maintenance operatives and health and safety officers.
Related products
- Type A – C Internal Corner Anchor, CSC Edilizia
- Internal Corner Anchor, CSC Edilizia
- Tensioner CSC Edilizia 438C — from the category Lifeline Accessories
- Fall-arrest harness Avao, European version, Petzl — from the category Fall Arrest Harnesses
- Lifeline 8 m two-pitch H40 cm CSC Edilizia 604C-8M-614-8M-614C-8M-1 — from the category Ropes and Temporary Lifelines
- Browse the whole category: Horizontal and Vertical Lifeline Anchors
Before you order
Tell us the quantities you need and the intended use: if there is a more suitable version, or an equivalent available sooner, we will let you know.
For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
Variant
Quantity
Specifications 5
| Material | S235JR (Fe 360 B) |
|---|---|
| Treatment | Galvanised |
| Regulations | UNI-ISO 2768 |
| Weight (kg) | 3,96 |
| Dimensions (cm) | 36 × 36 × 6 |
